s type load cell

The S Type Load Cell represents a sophisticated force measurement device designed in an S-shaped configuration, offering exceptional versatility and reliability in various industrial applications. This specialized sensor converts force into measurable electrical signals through precision strain gauges strategically mounted on the cell's body. The distinctive S-shaped design allows for both tension and compression measurements within a single unit, making it particularly valuable in industrial weighing systems, material testing, and process control applications. The cell's construction typically features high-grade alloy steel or stainless steel, ensuring durability and resistance to environmental factors. With capacities ranging from a few kilograms to several tons, S Type Load Cells deliver accurate measurements across diverse load ranges. Their design incorporates temperature compensation and offers protection against off-center loading effects, ensuring consistent performance in varying conditions. The cell's configuration allows for easy installation and maintenance, while its compact form factor makes it suitable for applications where space is limited. Advanced models feature hermetically sealed construction, providing protection against moisture and dust, which extends their operational lifespan and maintains measurement accuracy.

New Product Releases

S Type Load Cells offer numerous practical advantages that make them an excellent choice for various industrial applications. First, their unique design enables dual-direction force measurement, eliminating the need for separate sensors for tension and compression forces, which reduces equipment costs and simplifies installation processes. The cells provide exceptional accuracy and repeatability, typically achieving precision levels of 0.03% or better, ensuring reliable measurements across their operational range. Their robust construction ensures long-term stability and minimal maintenance requirements, resulting in lower lifetime operational costs. The compact design makes them particularly suitable for retrofitting existing systems or installing in spaces with limited room. These load cells demonstrate excellent resistance to side loading and off-center forces, maintaining accuracy even in challenging environmental conditions. Their versatility allows for easy integration with various mounting options and compatibility with standard industry interfaces. The cells feature built-in temperature compensation, ensuring consistent performance across different operating conditions. Their design also facilitates simple calibration procedures, reducing downtime during maintenance. The hermetically sealed versions offer superior protection against harsh environmental conditions, making them suitable for outdoor and wet applications. Additionally, their high overload capacity provides an extra safety margin, protecting the investment in case of unexpected load spikes.

Latest News

Linear Displacement Sensor: Understanding Its Calibration Process

12

May

Linear Displacement Sensor: Understanding Its Calibration Process

View More
What Are the Advantages of Linear Displacement Sensor?

16

Jul

What Are the Advantages of Linear Displacement Sensor?

View More
How to Choose Linear Displacement Sensor for Automation?

16

Jul

How to Choose Linear Displacement Sensor for Automation?

View More
Why Use LVDT Sensor for High-Precision Measurements?

16

Jul

Why Use LVDT Sensor for High-Precision Measurements?

View More

Get a Free Quote

Our representative will contact you soon.
Email
Name
Company Name
Message
0/1000

s type load cell

Superior Accuracy and Reliability

Superior Accuracy and Reliability

S Type Load Cells excel in providing exceptional measurement accuracy, typically achieving precision levels of 0.03% of rated capacity or better. This high level of accuracy is maintained through sophisticated strain gauge technology and precise manufacturing processes. The cells feature advanced temperature compensation systems that minimize measurement drift due to environmental temperature variations. Their design includes built-in protection against off-axis loading effects, ensuring measurement consistency even when forces are not perfectly aligned. The reliability of these cells is enhanced through rigorous quality control processes during manufacturing, including individual calibration and testing of each unit. This commitment to accuracy makes them ideal for applications requiring precise force measurement, such as laboratory testing, process control, and high-precision industrial weighing systems.
Versatile Application Capabilities

Versatile Application Capabilities

The unique S-shaped design of these load cells enables them to handle both tension and compression forces effectively, making them extraordinarily versatile in their application range. This dual-direction capability allows for simplified system design and reduced equipment costs. The cells can be easily integrated into various industrial processes, from basic weighing applications to complex force measurement systems. Their compact form factor makes them particularly suitable for applications where space is limited, while their robust construction allows them to perform reliably in harsh industrial environments. The versatility extends to their mounting options, with various standard mounting accessories available to facilitate installation in different configurations. This adaptability makes them ideal for applications in industries ranging from manufacturing and material testing to aerospace and automotive testing.
Durability and Environmental Resistance

Durability and Environmental Resistance

S Type Load Cells are engineered for exceptional durability and long-term reliability in demanding industrial environments. Constructed from high-grade alloy steel or stainless steel, these cells offer excellent resistance to mechanical wear and environmental factors. The hermetically sealed versions provide superior protection against moisture, dust, and other contaminants, making them suitable for use in challenging environments. Their robust design includes built-in overload protection, safeguarding the cell against damage from unexpected force spikes. The high-quality materials and construction techniques used in their manufacture ensure minimal maintenance requirements and extended operational life. This durability translates to reduced downtime and lower maintenance costs over the life of the equipment, making them a cost-effective choice for long-term industrial applications.
