Jiangxi SOP Precision Intelligent Manufacturing Technology Co.,Ltd.
Jiangxi SOP Precision Intelligent Manufacturing Technology Co.,Ltd.
| Place of Origin: | China |
| Brand Name: | SOP |
| Model Number: | SOPN-201D |
| Minimum Order Quantity: | 1pc |
| Packaging Details: | Paper box |
| Delivery Time: | 5 days |
| Payment Terms: | TT |
| Supply Ability: | 300pcs per day |
Quick Detail:
1. Strong anti-interference type, high precision and good stability.
2. Small size, light weight and easy to install.
3. Allows transmission of rotary, static and dynamic torque signals.
4. Alloy steel construction.
Description:
Torque sensor is a precision measuring instrument for measuring various torque, speed and
mechanical power.
Applications:
The scope of application is very wide, mainly used for:
1. Testing the output torque and power of rotating power equipment such as motors, engines, internal combustion engines;
2. Testing the torque and power of fans, water pumps, gearboxes, and torque wrenches;
3. Railway locomotives , Torque and power detection in automobiles, tractors, airplanes, ships, and mining machinery;
4. Can be used for torque and power detection in sewage treatment systems;
5. Can be used to manufacture viscometers;
6. Can be used in process industries and processesin industry
Specifications:
| Capacity | 0-500N. m |
| Speed Signal | 0-3000rpm |
| Zero Balance | ±0.5%F.S. |
| Non-Linearity | 0.1%F.S. |
| Hysteresis | 0.5%F.S. |
| Repeatability | 0.05%F.S. |
| Creep(30min) | 0.05%F.S. |
| Temp Effect on Output | 0.05%F.S./10℃ |
| Temp Effect on Zero | 0.05%F.S./10℃ |
| Response Frequency | 1kHz |
| Power supply | DC 5-15V |
| Maximum overload | 200% |
| Safe overload | 150% |
| Torque signal | <2.0mV/V |
| Cable size | Φ5*3m |
| Material | Alloy steel |
| Cable ultimate pull | 10kg |
