Shoe forming, pressing and cutting processes demand strict accuracy in stroke positioning and pressing depth. Traditional mechanical limit controls suffer large errors, which cannot meet the mass‑production requirements for high‑quality footwear. This draw‑wire displacement sensor, with its compact and robust design, acts as a key measuring component for upgraded automatic shoe‑making equipment.

The sensor adopts an aluminum‑alloy housing with a small footprint for easy mounting. It fits into the limited installation space of various shoe machines such as sole pressers, lasting machines and setting machines. Equipped with a precision spring‑rewind mechanism and wear‑resistant steel rope, it delivers smooth retraction. Featuring vibration and oil resistance, it stably operates in workshop environments with dust and frequent reciprocating motion without jamming or premature wear.

It captures real‑time linear displacement of oil cylinders and moulds, feeding back stroke and opening‑closing distance to the control system. Based on accurate measurement data, the machine realizes closed‑loop adjustment for consistent pressing force and forming dimension across batches. It reduces defective products and eliminates instability caused by manual adjustment.

Flexible signal output options allow seamless compatibility with shoe‑machine PLC systems. Retrofitting existing machines requires minimal mechanical modification. High repeat positioning accuracy guarantees uniform production quality, while long service life cuts maintenance costs. The sensor improves automation performance and production efficiency of shoe‑making machinery, supporting intelligent manufacturing in the footwear industry.
